ORIX MU1225S-41 AC200V aluminum AC cooling fan

model: MU1225S-41

Specifications: 120*120*25mm

Input voltage: AC200V

Input power: 11/9.5W

Working current: 0.05/0.06A

Working frequency: 50/60HZ

Swing speed: 2500/2950R/MIN

Maximum air volume: 56.5/67.1CFM

Noise: 36/40dBA

Direction of rotation: counterclockwise rotation from the rotor

Bearing structure: maintenance-free double ball bearing

Service life: 25. C time L10 life expectancy of 60,000 hours

Insulation class: 42DBA

Temperature range: -10.60. C

Material frame: aluminum frame

Blade: Polycarbonate (flame retardant grade)

Anti-burn ring device: built-in thermal protection device

Country of origin: Made in Japan
