BOE 10.1 Inch 1280x800 WXGA LCD Panel TFT IPS Display For medical imaging EV101WXM-N10 LVDS 40pins
- Stock: In Stock
- Brand: BOE
- Model: EV101WXM-N10
- Weight: 0.75kg
- Dimensions: 32.00cm x 22.00cm x 9.00cm
- SKU: EV101WXM-N10
- UPC: EV101WXM-N10
- JAN: EV101WXM-N10
- ISBN: EV101WXM-N10
- MPN: EV101WXM-N10
Products Sold: 0
Product Views: 65
$999.99
Ex Tax: $999.99
Price in reward points: 25
Manufacturer | BOE |
Model Name | EV101WXM-N10 |
Screen Size | 10.1 inch |
Pixel Number | 1280(RGB)×800,WXGA |
Active Area(mm) | 216.96(H) x 135.6(V) (H×V) |
Outline(mm) | 228.6(H) x 149.2(V) (H×V×D) |
Bezel Area(mm) | 216.96 × 135.6 (H×V) |
Treatment | Haze |
Luminance | 350 cd/m² (Typ.) |
Contrast Ratio | 900 : 1 (Typ.) (TM) |
Viewing Angle |
85/85/85/85 (CR≥10) Left/Right/UP/Down |
Response | 30 (Typ.)(Tr+Td) ms |
Work Mode | ADS,Normally black,Transmissive |
Color Depth | 16.2M,50% NTSC |
Backlight | WLED,30K hours,with LED Driver |
Net Weight | 195g (Typ.) |
Touchscreen | without |
Signal Type/interface Type | LVDS (1 ch, 8-bit),40 pins |
Voltage Supply | +3.3 V (Typ./Max.) |
Max. Ratings |
Storage Temp.: -20 ~ +70 (°C) Operating Temp.: -30 ~ +70 (°C) |
Package |
BOE Original package; 40 pcs/box; size : 500(W) x 400(D) x 300(H) mm |
Tags:
EV101WXM-N10
